High speed cap elevator device

Ø  The angle of the cap-falling area is adjustable for different sizes of caps

Ø  One machine suitable for various sizes of caps

Ø  Accuracy up to 99.9%

Ø  High speed, up to 60000 pcs/hours

Ø  Auto-start & stop when caps are insufficient and full.

The price includes

 ① cap storage tank,

② cap elevator

 ③ Dial-type divider

 ④ 3m conveyor

⑤ reject device

⑥ finished divider

More Reference Parts Images

UV Digital Printing System

1.Accurate on-demand variable data printing control

2.Intelligent ink system to ensure stable and continuous ink supply to print head

3.Constant Pressure System (standard) or Negative Pressure System (optional) ensures stable printing at high speed

4.Field upgradable firmware and system software

5.Automatic ink shortage alarming by ink level sensors

6.Head temperature setting and real-time monitoring

Our Software

Our Printer Control Software (PCS) installed on a PC is designed for scanning inkjet printing. It offers a user-friendly interface to interactively control the printer, monitor printer status, and set printer options, such as the amplitude and pulse width of jetting waveforms and the temperature for each print head.
The control interface features include database checking, data settings, DPI settings,motor speed settings, and print head settings, etc.

Variable Data Printing Software
Supporting several types of objects, such as text, dates, times, graphics, logos, serial numbers, barcodes, Windows Fonts, and database photo images.
Supporting to load data source file, including .CSV, .XLS, .XLSX, .TXT and PDF file. After loading, all the records in the source file will be displayed in the data field and you are able to select the field and bind it to the objects.
Multiple Languages Supported,such as English, Espanol, Deutsch, French, Portugal, Russian, Simplified Chinese and Traditional Chinese.
